Wenlio delivers world-class CNC broaching services that combine cutting-edge technology with uncompromising quality standards.
Our advanced machining capabilities can control your components tolerances within 0.02 mm.
Wenlio uses a dual-motor synchronized servo drive system engineered for high-tonnage broaching, delivering stable power output and precise process control. The machine features a dual-bed, opposed layout with the broaching zone positioned at the center, keeping the load path and broaching center in the same plane. This design helps improve rigidity and machining consistency, and supports a wide range of internal and external broaching applications.
Depending on part size and process requirements, stroke and fixturing can be configured accordingly, covering broaching needs from small precision components to large castings and forgings.
Need a non-standard spline? Ask Wenlio for a tooling evaluation.
Custom spline machining supplier
High-precision involute splines for power transmission, widely used in European automotive and industrial applications.
American National Standards for external and internal splines, ensuring interchangeability and performance
Including ISO 14 and ISO 4156 for splines and serrations, supporting global manufacturing consistency
Japanese Industrial Standards covering spline profiles for automotive and machinery parts, ensuring compatibility with Asian markets
Detailed step-by-step process documentation ensures every broaching operation meets exact specifications and repeatability
Custom calibrated gauges verify spline dimensions quickly on the shop floor, preventing out-of-tolerance parts from progressing
High-precision 3D inspection validates spline geometry, tooth profile, pitch, and concentricity with micron-level accuracy
Continuous monitoring of production data to detect trends and maintain process stability, reducing scrap and rework
Single-Pass Precision
Broaching is a single-pass process where tool and machine precision directly impact final part quality. Rigorous QC prevents costly assembly failures and ensures optimal fit and function in your critical applications.
Standards Compliance
Our inspection protocols align with ASME B5.54-2005 and ISO 230 series standards, ensuring compliance with industry best practices and international quality requirements across all manufacturing sectors.
Consistent Excellence
Regular machine maintenance and calibration underpin our ability to deliver consistent, high-quality splines batch after batch, maintaining tight tolerances throughout extended production runs.
Customize suitable cutting tools according to the complexity of the parts and the production quantity requirements.
Complex spline geometries with superior surface finish.
Engineering support (support@wenlio.com) from initial design review through final production delivery.
Integrated quality control and adherence to international standards minimizes costly rework
Partner with Wenlio for CNC broaching solutions that meet the high standards in quality, accuracy, and efficiency. Our commitment to precision manufacturing, combined with cutting-edge technology and rigorous quality control, meet your requirements for spline and keyway processing.
Reach out now and let us help you bring your vision to life with confidence, backed by decades of expertise and a track record of delivering exceptional results for clients across aerospace, automotive, and industrial sectors.
